The MPLAB ICD 2 is not recommended for new designs and will not support new MCU or dsPIC devices released after September 2010. Please consider the MPLAB ICD 3 (DV164035). Real-time data capture using multi-tasking with USB embedded host.Real-time data graphing using the ADC and display multi-tasking.USB Flash drive interface with USB embedded host peripheral.RGB LED Control with three PWMs and Peripheral Pin Select (PPS).Time and data display using the Real Time Clock and Calendar (RTCC).Capacitive touch sensing with the Charge Time Measurement Unit (CTMU).
Interactive, menu driven display using Parallel Master Port (PMP). A USB connection to a host computer supplies communications and power to the board -no additional external power supply is needed. The PIC24F Starter Kit includes integrated hardware debug and programmer circuitry to develop, program and test applications on the board’s PIC24F MCU device -all from the MPLAB graphical development environment. #Keil equipment software#
Older software distribution can be found in our archives. Once downloaded and installed, demos for this start kit include ‘PIC24F Starter Kit 1’ and nearly all USB related demo projects, please see the USB library release note for details.MPLAB Start Kit for the PIC24F demo support is now distributed as part of the Legacy Microchip Application Libraries(v) : Legacy MLA.The link to the Legacy libraries can also be found in the Documents/Software section below.
#Keil equipment plus#
Interface PICtail™ Plus Daughter Cards connected via vertical PICtail™ Plus connector through additional accessory - PICtail™ Plus Expansion Board. Interface PICtail™ Plus Daughter Cards connected via side PICtail™ Plus connector directly. Support for all the existing and new PICtail™ Plus Daughter Cards. Interfaces to MPLAB ICD 3, MPLAB REAL ICE™, PICkit™ 3. Integrated USB programmer/debugger - PICkit™-On-Board (PKOB). Microchip's TC1047A high accuracy, analog output temperature sensor. Alpha-numeric 16 x 2 LCD display, 8x User LEDs, 4x Push Buttons, 10k potentiometer. 2x MikroElektronika mikroBUS™ interface. Hardware functionality extension by attaching accessory boards via. USB Type-C™ (host/device) and Type-A (host) support for applications using USB microcontroller. On board USB to UART/I2C™ adapter for data exchange with PC/Mac/Linux based host. USB Power through PICkit™-On-Board (PKOB), USB Type-C™ or USB-Serial Converter. 100 pin Plug-In Module (PIM) socket, supporting a wide variety of 16-bit and 32-bit PIC® MCUs and dsPIC® DSCs. #Keil equipment code#
Download and unzip the appropriate firmware demo code (available at Documentation & Software section of this page). Download the suitable MPLAB XC Compiler.
#Keil equipment manual#
Read the Explorer 16/32 User's Manual (available at Documentation and Software section of this page). Re-use the PICtail Plus daughter cards interfaced via vertical PICtail Plus connector using additional PICtail Plus Expansion Board (AC240100) Use all of existing codes, libraries, prototypes, PIMs and the PICtail Plus daughter cards interfaced via side PICtail Plus connector directly. Code Examples, Ptototypes and Software Libraries developed on Classic Explorer 16 development Board. This board is optimal for customers migrating from Classic Explorer 16 to new Explorer 16/32 platform, while all the necessary additional components like Processor Plug-In Modules and PICtail™ Plus Daughter Boards are already availableĪlso read about Explorer 16/32 Development KitĮxplorer 16/32 Development Board is completely backwards compatible with the Classic Explorer 16 Development Board (DM240001 and DM240002) and its associated ecosystem that include:
Choose PIM of your choice based on MCUs and DSCs under consideration from wide range of Processor Plug-In Modules. Coupled with the integrated PICkit™-On-Board (PKOB), MPLAB ICD 3 In-Circuit Debugger or MPLAB REAL ICE™ real-time emulation and debug facilities enable faster evaluation and prototyping of application.Įxplorer 16/32 Development Board offers only the main board, giving the option to customize the other necessary components. In addition to the hardware features provided by the board, hardware expansion is possible through the use of PICtail™ Plus daughter cards and mikroBUS™ accessory boards. The board accepts Processor Plug-In Modules (PIMs) designed for the Explorer 16 or Explorer 16/32 development board for easy device swapping. It features all the necessary hardware to begin developing and debugging a complete embedded application. The Explorer 16/32 Development Board is a flexible and convenientdevelopment, demonstration and testing platform for 16-bit PIC24 MCUs, dsPIC ® DSCs and 32-bit PIC32 MCUs from Microchip Technology.
